Can Type Vertical Turbine Pump

The Can Type Vertical Turbine Pump is engineered for high-efficiency water transfer in industrial, municipal, irrigation, and deep well applications. Featuring advanced hydraulic design, corrosion-resistant materials, low-noise operation, and energy-saving performance, it delivers reliable high-capacity pumping with reduced maintenance and long service life in demanding operating environments.

Availability:

Quantity:



Inquire

Description

Specificaitons

Applications

Model Features

Installation

Using state-of-the-art techniques from USA in turbine pump design, Wangyang vertical turbine pump covers a wide range of hydraulic conditions to meet virtually every pumping service in the industry with optimum efficiency.

Advantage of Vertical Turbine Pump

• Advanced hydraulic model and structure design, Ashland process for core, Epoxy coated in blade passage of impeller, reasonable material selection, excellent product performance, long service life.

• High efficiency, higher 2~8%, than Local J、JD、JC Pump, with flat efficiency curve wide area for high efficiency add 10~20% separation range, significant energy saving effort

• The sand throwing apparatus, a labyrinth structure make the sand cannot enter the bearing

• Impeller and motor shaft is supported copper bearing, shaft runout control within American standard 0.13mm, smooth running, low noise.

• Pump discharge head has beautiful appearance, convenient repair window, is easy to replace packing

• Compared with the same domestic flow pump, the working parts of small diameter about 1 inches, renovation can significantly save the user cost and suitable for pumping well

Cross Sectional Drawing

APP-0

Specifications of Vertical Turbine Pump

Capacities to 20000 GPM (4500 m³/h)
Designed for high-volume liquid transfer applications, the pump delivers powerful and stable flow performance for municipal water supply, industrial processing, irrigation, and large-scale pumping
Heads to 1600 Feet (500m)
Capable of providing high-pressure water delivery for deep well pumping and long-distance transportation. Ensures reliable performance in demanding high-head applications.
Temperatures to 500°F (260°C)
Engineered to handle high-temperature liquids with excellent thermal stability, making it suitable for industrial circulation systems and harsh operating environments.
Bowl Sizes from 6" to 28"
Multiple bowl size options provide flexible system configurations to meet different flow capacities and installation requirements across various industries.
Casted or Fabricated Discharge Head and Flanged Column
Robust structural designs offer enhanced durability, pressure resistance, and installation flexibility for different operating conditions and project demands.
Flanged Bowl Construction
The flanged connection design improves assembly strength and simplifies maintenance, helping reduce downtime and improve long-term operational reliability.
Stainless Steel Shafting
High-strength stainless steel shafts provide superior corrosion resistance and long service life, even in aggressive or moisture-rich environments.
Alloy Construction with External Flush for Corrosive/Abrasive Services
Special alloy materials and external flushing protection minimize wear in critical areas, ensuring dependable operation in corrosive and abrasive applications.
Built-in Alignment and Simple Piping Design
Optimized alignment and simplified piping reduce installation complexity, lower maintenance costs, and improve overall operational efficiency with minimal downtime.

Material of Vertical Turbine Pump

Bowl: Cast Iron, Ductile Iron, Stainless Steel, Duplex SS, Bronze

Shaft: Carbon Steel, Stainless Steel, Duplex SS, 17-4PH SS, Model K500

Impeller: Cast Iron, Ductile Iron, Stainless Steel, Duplex SS, Bronze

Discharge head: Cast Iron, Ductile Iron, Fabricated Steel, Stainless Steel, Duplex SS

Applications of Vertical Turbine Pump

Utility Circulating Water	Waster Plants	Industrial Process
Golf Courses/Turf Irrigation	Agricultural Irrigation	Dewatering
Mining	Cooling Water	Water Parks
Snowing	Flood Control	Seawater and Raw Water Intake
Fire-Fighting	Condenser Circulating Water	Ash Sluice

The Vertical Turbine Pump is widely used in municipal, industrial, agricultural, and commercial applications requiring reliable high-capacity water transfer and stable pressure performance. Its advanced hydraulic design and high-efficiency operation make it an ideal solution for circulating water systems, wastewater treatment plants, industrial processing, and condenser cooling applications.

Designed for demanding environments, the pump performs exceptionally well in irrigation systems, golf course watering, mining operations, dewatering projects, and flood control applications. The durable construction and corrosion-resistant material options ensure long-term reliability even in abrasive, corrosive, or high-moisture operating conditions.

With excellent adaptability for seawater intake, raw water transportation, fire-fighting systems, water parks, and snowmaking applications, the Vertical Turbine Pump delivers continuous, energy-efficient performance while reducing maintenance requirements and operational downtime. Its flexible configuration options allow it to meet diverse project requirements across a wide range of industries.

Model Features

1. Pump Bowl Assembly

The bowl assembly is the heart of the vertical turbine pump. The impeller and diffuser type casing are designed to deliver the head and capacity that your system requires in the most efficient way possible. The fact that the vertical turbine pump can be multi-staged allows maximum flexibility both in the initial pump selection and in the event that future system modifications require a change in the pump rating.

A variety of material options allows the selection of a pump best suited for even the most severe services. The many bowl assembly options available ensure that the vertical turbine pump satisfies the users' needs for safe, efficient, reliable and maintenance-free operation.

2. Flanged Column

Column sections are provided with flanged ends incorporating registered fits for ease of alignment during assembly to ensure concentricity. Our standard bearing retainers are threaded into the column section. Product lubricated lineshaft is recommended for ease of maintenance. Renewable shaft sleeve or hard facing of shaft available for longer life. The enclosed lineshaft is protected by water flushing the enclosing tube bearing on corrosive / abrasive services. Oil lubricated lineshaft available on long settings.

3. Discharge Head

The discharge head functions to change the direction of flow from vertical to horizontal and to couple the pump to the system piping in addition to supporting and aligning the driver. Discharge head accommodates all types of driver configurations. Optional sub-base can be supplied. Wangyang offers three basic types for maximum flexibility.
